| 프레임 |
슈퍼폭시 29 6061 스텔스 알로이 , hydroformed tubing, Zero Suspension System, 160mm travel, Forward Geometry, one piece Monoblock upper link, SuperBoost 12x157mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpo |
| 사이즈 |
S: 380mm / M: 420mm / L: 470mm / XL: 510mm |
| 리어샥 |
폭스 Float-X LV 퍼포먼스, 205x65mm. Settings: compression 2 positions lever, low-speed rebound, air preload. Trunnion top mount, 22.2x10mm bottom bushings |
| 샥 세팅 |
Medium compression, Medium rebound, 0.2 air volume spacer |
| 포크 |
폭스 38 29 Float GRIP 리듬 170mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: 3 positions with micro adjust compression, low-speed rebound, air preload |
| 헤드 세트 |
온오프 Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
| 핸들 스템 |
온오프 Sulfur FG 30mm 0º, 알로이, 31.8mm barbore |
| 핸들 바 |
온오프 Sulfur 1.0, 알로이, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
| 핸들 그립 |
온오프 Twin, 1lock-on, 135mm |
| 시트 포스트 |
온오프 Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm |
| 안장 |
SDG BEL-AIR 3.0, LPU foam, steel rails |
| 브레이크(앞,뒤) |
스램 DB8, 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed organic pads |
| 브레이크 레버 |
스램 DB8, tool-free reach adjust |
| 림 |
e*thirteen LG1 Enduro, IW30 Hookless, 6069 Welded Aluminum, 30mm internal width, tubeless ready, 28 spokes |
| 스포크 |
e*thirteen custom Hive triple-butted black steel, alloy nipples, nipple washers |
| 허브(앞) |
e*thirteen Boost 15x110mm, triple-sealed, fully machined aluminum, IS 6 bolts |
| 허브(뒤) |
e*thirteen Superboost 12x157mm, triple-sealed, fully machined aluminum w/6-degree engagement, IS 6 bolts, Shimano freehub |
| 타이어(앞) |
맥시스 Assegai 29x2.5WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead |
| 타이어(뒤) |
맥시스 Dissector 29x2.4WT, tubeless ready, 3C MAXX GRIP compound, DH casing, 60x2TPI, folding bead |
| 크랭크 세트 |
트루바티브 Descendant 7K 이글, SuperBoost, DUB axle, Direct mount chain ring, S/M size: 170mm, L/XL size: 175mm |
| 체인링 |
32T, CNC-machined alloy, X-SYNC 2 |
| BB |
스램 DUB BSA, sealed bearings, 73mm |
| 체인 |
스램 SX 이글, 12s, Powerlock |
| 변속기(뒤) |
스램 SX 이글, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1 |
| 변속 레버 |
스램 Trigger SX 이글, 12s, X-Actuation 1:1 |
| 스프로킷 |
스램 PG-1210, 11-50T, 12s |
| 행거앤드 |
몬드래커 M068 |
| 무게 |
17.2 kg |
레이싱실버/블루마린
레이싱실버/블루마린
레이싱실버/블루마린
