| Frame |
Podium 29 Stealth Air Carbon, XC Forward Geometry, BSA bottom bracket, tapered head tube, HHG internal cable routing, Boost 12x148mm rear axle, dedicated 1X drivetrain design, Flatmount brake compatible, |
| Fork |
Rockshox SID SL Ultimate RL 29, 100mm, Charger Race day, Debonair, tapered steerer tube, Boost 15x110mm axle, 32mm aluminum stanchions, offset 44mm. Settings: OneLock 2 position remote compression (open/lock), low-speed rebound, air preload |
| Headset |
Onoff Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º |
| Stem |
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: sizes S/M: 60mm, size L: 70mm, size XL: 80mm |
| Handlebar |
Onoff Helium Carbon 0.2, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore |
| Grips |
Onoff Desert, 1lock-on, 135mm, sizes: S/M L/XL |
| Seatpost |
Onoff Helium Carbon 0-R VFLEX, diameter 27.2mm, length 400mm |
| Saddle |
Fizik Antares R7 |
| Front brake |
Sram Level TLM, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
| Rear brake |
Sram Level TLM, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
| Brake lever |
Sram Level TLM, Direct Link actuation, tooled reach adjust, lever pivot bushings |
| Rims |
Mavic Crossmax SLR Carbon 29, 26mm internal width, hookless, UST tubeless, 28 spokes |
| Spokes |
Mavic steel butted, bladed, straightpull |
| Front hub |
Mavic Boost 15x110mm, IS 6 bolts |
| Rear hub |
Mavic Boost 12x148mm, 24T Ratchet system, IS 6 bolts, XD freehub |
| Front tire |
Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead |
| Rear tire |
Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead |
| Crankset |
Sram X01 Carbon Eagle, Boost, DUB axle, Direct mount chain ring, S size: 170mm, M/L/XL size: 175mm |
| Rings |
34T, CNC-machined alloy, X-SYNC 2 |
| Bottom bracket |
Sram DUB BSA, sealed bearings, 73mm |
| Chain |
Sram GX Eagle, 12s, Powerlock |
| Rear derrailleur |
Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1 |
| Shift levers |
Sram Trigger GX Eagle, 12s, X-Actuation 1:1 |
| Casette |
Sram XG-1275, 10-50T, 12s |
| Derailleur hanger |
Sram UDH |
| Sizes |
S: 390mm / M: 420mm / L: 470mm / XL: 510mm |
| Weight |
8.4 kg |
(무광)블랙 / 플레임레드 / 라이트블루
