| Frame |
Chrono 29 Stealth full Carbon, XC Forward Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable routing, Boost 12x148mm rear axle, Comfort Flat chainstays (Flatstays) design |
| Fork |
Rockshox SID SL Ultimate RL 29, 100mm, Charger Race day, Debonair, tapered steerer tube, Boost 15x110mm axle, 32mm aluminum stanchions, offset 44mm. Settings: OneLock 2 position remote compression (open/lock), low-speed rebound, air preload |
| Headset |
Onoff Titan tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41.8x30.5x8x45ºx45º, bottom 51.9x40x8x45ºx45º |
| Stem |
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-5º, length: size S: 60mm, size M: 70mm, size L: 80mm, size XL: 90mm |
| Handlebar |
Onoff Sulfur 0.2, double butted 6061 alloy, rise: 4.8mm, width: 740mm, 9º backsweep, 0º upsweep, 31.8mm barbore |
| Grips |
Onoff Desert, 1lock-on, 135mm, sizes: S/M L/XL / |
| Seatpost |
Onoff Sulfur 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm |
| Saddle |
Mondraker XC Series, steel rail |
| Front brake |
Sram Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
| Rear brake |
Sram Level T, 2 piece caliper, Centerline 160mm IS 6 bolts one-piece rotor, steel-backed organic pad |
| Brake lever |
Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings |
| Rims |
DT Swiss X1900 Spline 29, 25mm internal width, sleeved aluminum, tubeless ready, 28 spokes |
| Spokes |
DT Champion, straightpull |
| Front hub |
DT 370, Boost 15x110mm, IS 6 bolts |
| Rear hub |
DT 370, Boost 12x148mm, 3 Pawl system, IS 6 bolts, MS freehub |
| Front tire |
Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead |
| Rear tire |
Maxxis Ikon 29x2.20, 3CMaxx Speed compound, tubeless ready, 120TPI, folding bead |
| Crankset |
Shimano XT M8100 Boost, Hollowtech II, Q-factor 172mm, S size: 170mm, M/L/XL size: 175mm |
| Rings |
34T, CNC-machined alloy |
| Bottom bracket |
Shimano XT MT800 BSA, 68/73mm |
| Chain |
Shimano Deore M6100, 12s, Quick-link |
| Rear derrailleur |
Shimano XT M8100, SGS, Shadow+, 12s |
| Shift levers |
Shimano Deore M6100, Rapid Fire Plus, 12s |
| Casette |
Shimano Deore M6100, 10-51T Hyperglide+, 12s |
| Derailleur hanger |
Mondraker M068 |
| Sizes |
S: 395mm / M: 430mm / L: 470mm / XL: 520mm |
| Weight |
10.2 kg |
블랙 / SID블루 / 라이트블루
