| 프레임 |
Foxy 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 150mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, 73mm BSA bottom bracket, dedicated 1x drivetain design, telescopic seatpost internal rout |
| 리어샥 |
RockShox Deluxe RL, 205x62.5mm, DebonAir. Settings: rebound, 2-position compression adjustment (Openl/Lock), air preload. Trunnion top mount, 22.2x10mm bottom bushings |
| 샥 셋팅 |
Medium compression, medium rebound, lock out force 430, air volume reducers 2 Tokens |
| 헤드셋 |
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
| 포크 |
RockShox Yari RC Motion control 29, 160mm, DebonAir, tapered steerer tube, 15x110mm axle, offset 42mm. Settings: low-speed compression to lock, rebound, air preload |
| 핸들바 |
Mondraker double butted 6061 alloy, rise: 12mm, width: 780mm, 9º backsweep, 5º upsweep, 31.8mm barbore |
| 핸들스템 |
Onoff Stoic FG 30mm, 6061 forged alloy, 31.8mm barbore |
| 시트포스트 |
Onoff Pija dropper internal, diameter 31.6mm, S size: 337x100mm, M size 387x125mm, L/XL size: 425x150mm |
| 브레이크 |
Shimano MT501, RT66 203mm IS 6 bolts rotor, resin pads |
| 변속레버 |
Sram Trigger NX Eagle, 12s, X-Actuation 1:1 |
| 뒤 변속기 |
Sram NX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-actuation 1:1 |
| 기어크랭크 |
SRAM NX Eagle, Boost, DUB axle, Direct Mount chain ring, S/M size: 170mm, L/XL size: 175mm |
| 스프라켓 |
Sram PG-1230, 11-50T, 12s |
| 체인 |
Sram NX Eagle, 12s |
| 림 |
MDK-EP1 29 TLR ASY, asymmetrical rim, 27mm internal width, tubeless ready, 32 sp |
| 앞 허브 |
MDK GW 15x110mm, sealed bearings, IS 6 bolts |
| 뒤 허브 |
MDK GW 12x148mm, sealed bearings, IS 6 bolts |
| 타이어 |
Maxxis Minion DHR II 29x2.4 WT, Tubeless ready, 3C MAXX TERRA compound, Exo prot |
| 페달 |
미포함 |
| 무게 |
14.7kg |
| 행거앤드 |
Mondraker M068 |
