| 프레임 |
Chrono 29 6061 Xtralite Alloy butted, Avant Geometry, 73mm BSA bottom bracket, tapered head tube, HHG Internal Cable Routing, Boost 12x148mm rear axle |
| 헤드셋 |
Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º |
| 앞포크 |
RockShox 30 Silver 29, 100mm, Solo Air, tapered steerer tube, 9x135mm axel, 30mm steel stanchions, offset 51mm. Settings: 2 pos remote compression (open/lock), rebound, air preload |
| 핸들스템 |
MDK, 6061 T6 Alloy, 31.8mm barbore, rise: +/-6º, length: sizes S/M: 60mm, size L: 80mm, size XL: 90mm |
| 핸들바 |
MDK 0.2, double butted 6061 alloy, rise: 4.8mm, width: 720mm, 9º backsweep, 0º upsweep, 31.8mm barbore |
| 그립 |
Onoff Wave, 130mm |
| 시트포스트 |
MDK 0-R, 6061 T6 Alloy, 3D forged, diameter 27.2mm, length 400mm |
| 안장 |
Mondraker Chrono design |
| 앞 브레이크 |
Shimano MT201, RT56 160mm IS 6 bolts rotor, resin pads |
| 뒤 브레이크 |
Shimano MT201, RT56 160mm IS 6 bolts rotor, resin pads |
| 브레이크 레버 |
Shimano MT201, tooled reach adjust |
| 시프터 레버 |
Sram Trigger NX, 11s, X-Actuation 1:1 |
| 뒤 변속기 |
Sram NX, Type 3 roller bearing clutch, cage lock, long cage, 1x11s, X-actuation 1:1 |
| 버텀브라켓 |
Sram GXP XR, sealed bearings, 73mm |
| 크랭크 |
Sram NX, 11s, Boost, 24mm axle, Direct Mount chain ring, S size: 170mm, M/L/XL size: 175mm |
| 체인링 |
32T, steel, X-Sync |
| 스프라켓 |
Sunrace CSMS8, 11-46T, 11s |
| 체인 |
Sram PC-1110, 11s |
| 림 |
MDK-XP1 29 TLR, 23mm internal width, tubeless ready, 32 spokes |
| 스포크 |
CN round stainless steel |
| 앞 허브 |
MDK DC20LW 9x135mm, cup & cone ball bearings, IS 6 bolts |
| 뒤 허브 |
MDK GW 12x148mm, sealed bearings, IS 6 bolts |
| 타이어 |
Kenda Slant Six 29x2.35, DTC, 60TPI, Wire bead |
| 행거앤드 |
Mondraker M068 |
| 무게 |
12.5 Kg |
| 페달 |
미포함 |
